Key
Specifications/Special Features:
■ Intel
4-core Bay Trail N2930 / J1910/ E3845 CPU
■ Support
DDR3 800, up to 8GB
■ Support
DVI-I: Integrated 7th Intel Graphics
■ DX11,
OGL3.2, max. 1920x1200 resolution
■ 24-bit
LVDS: max. 1920x1200
■ SATA2
x 1, mSATA x 1
■ Audio
■ Gigabit
LAN x 2
■ mini-PCIe
socket x 2
■ COM
x 4 (RS-232/422/485x1 + RS-232x3)
■ USB3.0
x 1, USB2.0 x 6
■ GPIO
x 8
■ +9V
~ +24V DC-IN
Specifications:
|
CPU |
INTEL Bay Trail 4-core N2930 CPU, 1.86GHz, 7.5W TDP
INTEL Bay Trail 4-core J1910 CPU, 2GHz, 10W TDP
INTEL Bay Trail 4-core E3845 CPU,1.91GHz, 10W TDP (need MOQ) |
|
Memory |
1 x SO-DIMM DDR3L 1333MHz, up to 8GB
|
|
Power Management |
ACPI S3 Compliant, support Power saving mode
|
|
DVI-I Interface |
Integrated 7th Intel Graphics support DX11, OGL3.2, max.
1920x1200 resolution
|
|
LVDS |
24bit Dual Channel LVDS, max. 1920x1200
|
|
SATA2 Interface |
1 x SATA2 (3GB/s) Device Support
1 x mSATA / mini-PCIe full-size mini-PCIe socket
|
|
Audio |
Realtek ALC662 HD Audio Codec
|
|
2xLan |
Realtek RTL8111G Gigabit LAN x 2
|
|
2xmini-PCIe socket |
1 x SATA2 (3GB/s) Device
Support
1 x mSATA / mini-PCIe full-size mini-PCIe socket |
|
4xCOM |
RS-232/422/485 x 1 + RS-232 x 3
|
|
USB |
USB3.0 x 1
USB2.0 x 6 |
|
|
PS/2 KB/Mouse
|
|
GPIO |
4 IN / 4 OUT
|
|
BIOS |
AMI UEFI
|
|
Power Requirement |
+9V ~ +24V DC-IN
|
|
Dimension |
146 mm x 102 mm
|
|
Temperature |
Operating within 0~ 60 centigrade
|
|
|
