Key
Specifications:
The Industrial Series (RS-422/485 to
Fiber) Converter provides a reliable and economical solution for
your industrial Ethernet environment. The converter offers
seamless integration while working as transparent device between
your serial devices and industrial Ethernet. The Converter has
operating temperature range from 0 to 50°C. Fiber enables you to
extend the distances.
Features:
■
Complies
with EIA/TIA-422 & 485
standards
■
Supports
data transfer rate up to 115.20kbps
■
Available
with SC connector for Multi
Mode
■
Wavelength: 1310nm
■
Extends
distance of up to 2km (6600 feet) multi-mode fiber
■
DIP switch for 4-wire full
and 2-wire asynchronous transmission
■
Extends distances up to 1.2km
for 24AWG Twisted Pair Cable
■
DIP switches to
enable/disable Termination
■
LEDs for at-a-glance device
status
■
Suitable for industrial harsh
environment
■
Wide voltage range (9 ~ 32V
DC)
■
FCC Class A & CE approved
■
Physical and Environmental
|
Power Input
|
9-32V DC @ 800mA
|
|
Temperature
|
Operating: 0° ~ 50° C, Storage: -20° ~ 80° C
|
|
Humidity
|
Operating: 10% ~ 80%
|
|
Dimensions
|
109.20 x 90 x 31.50 mm (D x W x H)
|
|
Compliance
|
FCC Class A, CE approved
|
|
|
