Key Specifications/Special Features:

7” 500 cd/m² TFT LCD with projective capacitive touchscreen
Texas Instruments Sitara ARM Cortex A8 CPU
Powered by Android 2.3 OS
1D laser / 2D imager scan engine, RFID reader
5 Megapixels CMOS rear camera and 2 Megapixels CMOS front camera
Bluetooth, Wi-Fi, 3.5G wireless
Built-in GPS with internal antenna
Dual hot swappable batteries

Specifications:



Display
LCD Size	7.0" TFT LCD
Brightness (cd/m2)	500
Max Resolution	800(H) x 480(V)
Touch Screen	Projective Capacitive Touch
Viewing Angle	60/70/70/70 Deg
System
CPU	TI Sitara AM3715
Operating System	Android 2.3.4
Memory	4GB eMMC Flash + 512MB SDRAM
Storage	SD Slot
Communication
Wireless Lan	Wi-Fi 802.11/b/g/n
Bluetooth	Bluetooth® 2.1 + EDR
Modem	WCDMA/HSDPA/GSM
GPS	GPS with internal antenna
Data Collection
RFID	13.56MHz HF RFID ISO 14443A(Mifare) ISO 14443B(Felica) ISO 15693 NFC
Barcode	1D/2D Imager Scan Engine
Camera (Front)	2 Megapixels CMOS camera
Camera (Rear)	5 Megapixels CMOS camera
Indicator & Buttons
Keys	Power On/Off switch Reset Key 4 x Function Key (Home/Menu/Back/Search)
LED Indicator	Charging StatusLED (Orange/Green) WiFi Enable/Disable LED (Green) BT Enable/Disable LED (Blue) 3G Enable/Disable LED (Green)
I/O Interface
Audio	1 x Headset 1 x 1.5W Speaker 1 x Digital Mic
Expansion	2 x USB2.0 1 x DC Jack
Power
Power adapter	19V @ 2.1A @ 40W
Battery	Dual 11.1V 1880mAh Li-ion battery
Environment
Operating Temperature	-10°C to +40°C
Storage Temperature	-10°C to +60°C
Humidity	5%~95% non-condensing
Drop Survival	1.2M
Environmental Protection	IP64
Certification	CE/FCC
Dimensions (LxWxH) (mm)	248x153x36
Weight	0.95kg
